KEMMLER radial tool holder VDI25 shape B7 16x3 mm
Brand: KEMMLER
Art.-no. 22740210
Manufacturer article no. 259.37.16
Application
Primarily for external machining or face grooving
Execution
- Alloyed case-hardening steel with a core tensile strength of at least 950 N/mm²
- Case-hardened, HRC 60 ± 2 (HV 700 ± 50)
- Hardness depth 0.8 mm ±0.2 mm
- black-oxide and precision-ground finish
- With internal coolant supply or with threaded connection for external coolant supply
- With adjustable ball spray nozzle and shim
- Right, long, overhead version
Notes
Previous standard DIN 69880/VDI 3525
Delivery
1x VDI radial tool holder shape B7 overhead, right, long
 | |
Brand | KEMMLER |
Manufacturer Part Number | 259.37.16 |
Harmonized System Code | 84669360 |
Gross Weight | 0.850 kg |
Certificates/ Documents (1)
