KEMMLER rectangular tool holder with multiple seats VDI40 shape D2 25-72 mm

Name: KEMMLER rectangular tool holder with multiple seats VDI40 shape D2 25-72 mm
Brand: KEMMLER
SKU: 22740489

Brand: KEMMLER

All versions

Application

Primarily for external machining or face grooving. To accommodate several lathe tools at the same time

Execution

Alloyed case-hardening steel with a core tensile strength of at least 950 N/mm²
Case-hardened, HRC 60 ± 2 (HV 700 ± 50)
Hardness depth 0.8 mm ±0.2 mm
black-oxide and precision-ground finish
With internal coolant supply or with threaded connection for external coolant supply
With adjustable ball spray nozzle and shim
Overhead version

Notes

Previous standard DIN 69880/VDI 3525

Delivery

1x VDI rectangular multi-tool holder shape D2
